Product Overview
The HOTTEN 20-Core Medical Equipment Cable is designed for multi-conductor connections in compatible medical devices and medical equipment systems.
Featuring 20 cores, tinned copper conductors and a PVC outer sheath, this cable provides a customizable wiring solution for equipment manufacturers requiring multiple electrical connections within a single cable structure.
The cable configuration can be defined according to the customer's technical requirements, including conductor size, core arrangement, insulation, overall diameter, cable length and connection interfaces. These parameters should be confirmed against the equipment wiring diagram and approved cable specification before production.
HOTTEN supports customized cable development based on customer drawings, reference samples and project requirements, helping OEM customers specify cable constructions that match their equipment design.
Key Features
20-Core Cable Configuration
The 20-core construction accommodates multiple conductors within a single cable. Core identification, conductor assignment and wiring layout can be specified according to the equipment design.
Tinned Copper Conductors
Tinned copper conductors are specified for this cable configuration. Conductor size, strand construction and electrical characteristics should be confirmed according to the approved technical specification.
PVC Outer Sheath
The PVC outer sheath provides an external protective covering for the cable. Jacket material grade, color, flexibility and applicable environmental requirements can be defined for the intended application.
Customized Cable Construction
Conductor gauge, insulation structure, outer diameter, cable length and other construction details can be specified according to customer drawings or reference samples.
OEM Cable Manufacturing
HOTTEN supports customized cable projects for medical equipment manufacturers. Cable construction and any required connector termination can be reviewed according to the project specification and requested scope of supply.
Technical Specifications
| Item | Specification |
|---|---|
| Product Type | Medical Equipment Cable |
| Core Configuration | 20 Cores |
| Conductor Material | Tinned Copper |
| Conductor Size | To be confirmed |
| Conductor Construction | To be confirmed |
| Individual Core Insulation | To be confirmed |
| Outer Sheath Material | PVC |
| Overall Cable Diameter | To be confirmed |
| Shielding Construction | To be confirmed |
| Electrical Characteristics | According to project requirements |
| Cable Length | Customized |
| Core Identification | According to wiring requirements |
| Connector / Termination | Optional, subject to project requirements |
| Application | Compatible Medical Equipment Wiring and Interconnections |
| Manufacturing Type | Custom Cable / OEM |
Final specifications depend on the approved drawing, reference sample and selected cable configuration.
Typical Applications
The 20-core cable can be evaluated for wiring and interconnection requirements in compatible medical equipment, including:
Medical equipment internal wiring
Medical device signal connections
Multi-conductor equipment interconnections
Customized diagnostic equipment
OEM medical equipment cable projects
The final application suitability depends on the required electrical performance, cable dimensions, material specifications and equipment interface.
Engineering & Procurement Considerations
When selecting a 20-core medical equipment cable, engineers should evaluate conductor requirements, wiring configuration, cable dimensions and the intended operating environment together.
1. Core Assignment and Wiring Requirements
Provide a wiring diagram that identifies the function of each conductor. Core colors, conductor assignment and termination details should be documented to support assembly and inspection.
2. Conductor Size and Electrical Requirements
Specify the conductor gauge, current or signal requirements, and applicable electrical acceptance criteria. The 20-core configuration and tinned copper material alone do not define the cable's electrical performance.
3. PVC Sheath and Cable Dimensions
Define the required outer diameter, dimensional tolerance, jacket flexibility and cable routing conditions. Confirm the PVC material requirements according to the equipment's operating environment.
4. Shielding and Signal Integrity
If the cable carries noise-sensitive signals or requires electromagnetic interference protection, specify the shielding construction and grounding arrangement. Shielding should not be assumed unless included in the selected design.
5. Connector and Termination Requirements
If the finished cable requires connectors, provide connector part numbers, interface drawings, pin assignments and termination requirements. Confirm whether the project requires a cable only or a completed cable assembly.
6. Quality and Compliance Requirements
Define the required continuity, dimensional and electrical tests, as well as any material or regulatory requirements applicable to the finished product. Medical equipment use does not automatically mean that every cable configuration is patient-contact rated or suitable for sterilization; such requirements must be verified for the specific design.
Custom 20-Core Medical Equipment Cable Manufacturing
HOTTEN supports customized cable development based on drawings, reference samples and technical specifications for medical equipment manufacturers.
For an engineering review and quotation, please provide:
Required core count and conductor gauge
Conductor and insulation specifications
Cable drawing or reference sample
Target outer diameter and cable length
PVC sheath requirements
Core identification and wiring diagram
Shielding requirements, if applicable
Connector part numbers and termination details, if required
Estimated order quantity and relevant quality requirements
HOTTEN can review the proposed construction and manufacturing requirements to support customized 20-core medical equipment cable projects.
Request a Custom Medical Equipment Cable Quote
Send your drawing, reference sample or cable specification to discuss a customized 20-core medical equipment cable for your application.
