MHF1 1.37mm Micro Coaxial RF Cable Assembly

MHF1 1.37mm Micro Coaxial RF Cable Assembly

HOTTEN manufactures customized MHF1 1.37mm micro coaxial RF cable assemblies for compact RF, wireless, UAV, drone video transmission and endoscopic equipment applications.

This miniature RF cable assembly combines a 1.37mm micro coaxial cable with an MHF1-type micro RF connector interface, providing a compact solution for connecting antennas, RF modules and electronic circuits where internal installation space is limited.

The small-diameter coaxial structure allows the cable to be routed through compact equipment while maintaining the controlled electrical characteristics required for RF signal transmission.

The referenced cable assembly is designed for applications including drone video transmission systems and endoscopic equipment, and HOTTEN can customize cable length, connector configuration, routing and other mechanical or electrical requirements for OEM projects.

Key Features

🔹 1.37mm miniature coaxial cable for compact equipment
🔹 MHF1 micro RF connector for high-density internal connections
🔹 Suitable for RF and wireless signal transmission
🔹 Compact diameter for tight routing spaces
🔹 Suitable for UAV and drone video transmission systems
🔹 Applicable to compact medical and endoscopic equipment
🔹 Flexible cable routing for confined internal structures
🔹 Custom cable length and connector configuration
🔹 OEM prototype and volume production support

Technical Specifications

Note: Final impedance, frequency range, attenuation, VSWR and other electrical specifications should be confirmed according to the customer's equipment and RF system design.

Why Choose HOTTEN for MHF1 Micro RF Cable Assemblies?

📡 Micro Coaxial Cable Engineering

HOTTEN focuses on micro coaxial cables and miniature RF cable assemblies for compact electronic equipment.

The 1.37mm cable format is suitable for applications that require a balance between miniature dimensions, flexible routing and reliable RF interconnection.

🔌 MHF1 Connector Integration

The MHF1 connector provides a compact RF interface for equipment where PCB area and internal mechanical clearance are limited.

HOTTEN supplies the complete cable assembly, integrating the micro coaxial cable and connector rather than simply supplying individual components.

⚡ Reliable RF Interconnection

RF cable assemblies must maintain suitable electrical characteristics while being routed through complex internal structures.

HOTTEN can develop cable assemblies according to the customer's required impedance, frequency, length, connector and mechanical routing specifications.

🏭 OEM Customization

HOTTEN supports customization of:

• Cable length

• MHF1 connector configuration

• Connector orientation

• Cable routing

• Cable construction

• Impedance

• Shielding structure

• Assembly requirements

This allows the finished cable assembly to be integrated into the customer's equipment design.

MHF1 1.37mm RF Cable for UAV and Drone Systems

UAV and drone platforms often require miniature RF interconnections because cameras, communication modules, antennas and electronic boards are installed within a restricted internal space.

A 1.37mm MHF1 micro coaxial cable assembly can provide a compact connection between RF modules, antennas and other electronic components.

Typical requirements include:

🚁 Lightweight and compact construction
📡 Stable RF signal transmission
🔌 Miniature connector integration
📐 Flexible internal routing
📷 Integration with camera and video systems

The small cable diameter is particularly useful where larger coaxial cable constructions would make routing difficult or occupy excessive internal space.

MHF1 RF Cable for Endoscopic Equipment

Endoscopic and other compact medical equipment require cables that can fit inside highly constrained mechanical structures.

The 1.37mm micro coaxial cable provides a miniature interconnect option for RF and signal-related applications where cable size and routing flexibility are important design considerations.

For medical equipment projects, cable construction, insulation, shielding, connector configuration and electrical performance can be customized according to the equipment requirements.

Applications

🚁 UAV & Drone Video Transmission

Miniature RF cable assemblies can connect compact wireless or RF modules used in UAV and drone video transmission systems.

📡 Antenna Connections

MHF1 cable assemblies can be used for connections between compact antennas, RF modules and PCB interfaces.

🔬 Endoscopic Equipment

The small-diameter structure is suitable for internal cable routing in endoscopic and other compact medical devices.

📶 Wireless Electronic Systems

The cable assembly can be used for internal RF interconnections in compact wireless equipment.

📷 Camera & Imaging Systems

Miniature coaxial cables can support RF or high-frequency connections in compact imaging architectures.

🤖 Robotics & Smart Electronics

The small cable diameter can help simplify internal RF routing in robotic and intelligent electronic systems.

Typical Purchasing Requirements

When sourcing an MHF1 1.37mm RF cable assembly, buyers should normally define:

Connector: MHF1 / compatible interface
Cable diameter: 1.37mm
Impedance: typically 50Ω for RF systems
Cable length: customized
Frequency range: application dependent
Connector orientation: customized
Cable routing: according to internal equipment structure
Application: UAV / antenna / wireless / medical / RF electronics

Providing these parameters allows the cable supplier to select the appropriate coaxial construction and connector assembly.

Custom MHF1 RF Cable Assembly for OEM Projects

HOTTEN provides customized MHF1 micro coaxial RF cable assemblies for electronics manufacturers, engineering teams and OEM customers.

The cable assembly can be developed around the customer's mechanical layout, connector interface and electrical requirements, including customized cable length, routing and connector orientation.

HOTTEN supports projects from engineering samples and prototypes through volume production, providing a complete micro RF cable assembly rather than only a loose cable or connector.

FAQ

❓ F: What is an MHF1 1.37mm RF cable assembly?
A: It is a miniature RF cable assembly combining a 1.37mm micro coaxial cable with an MHF1-type micro RF connector for compact electronic and RF applications.

📡 F: What is the typical impedance of an MHF1 RF cable?
A: A 50Ω configuration is commonly used for RF applications, but the final impedance should be confirmed according to the customer's system requirements.

📐 F: Why use a 1.37mm micro coaxial cable?
A: The 1.37mm diameter provides a compact form factor while allowing flexible routing inside space-constrained electronic equipment.

🚁 F: Can MHF1 cable assemblies be used in UAV and drone systems?
A: Yes. The referenced product is designed for drone video transmission systems and can be customized for compact UAV RF applications.

🔬 F: Can this cable be used in endoscopic equipment?
A: Yes. The referenced product is also intended for endoscopic equipment, where miniature cable dimensions and flexible routing can be important.

🔌 F: Can the MHF1 connector orientation be customized?
A: Yes. Connector configuration and orientation can be customized according to the customer's mechanical design.

🔧 F: Can HOTTEN customize the cable length?
A: Yes. HOTTEN supports customized cable lengths, connector configurations and cable assembly structures.

🏭 F: Does HOTTEN supply complete RF cable assemblies?
A: Yes. HOTTEN manufactures complete customized micro coaxial RF cable assemblies with integrated connectors.

📦 F: Does HOTTEN support OEM and volume production?
A: Yes. HOTTEN supports customized RF cable development from prototype and engineering samples through volume production.
