HRS DF80 30Pin 40AWG Micro Coaxial Cable Assembly for High-Speed Applications

Product Details

The HRS DF80 30Pin 40AWG Micro Coaxial Cable Assembly is a compact high-density interconnection solution for high-speed signal transmission in consumer electronics and other space-constrained electronic equipment. The HRS DF80 30-pin connector configuration combined with 40AWG micro coaxial cable provides a compact cable assembly option for applications requiring dense signal routing and small installation space.

HOTTEN supports OEM and ODM customization according to customer drawings, connector part numbers, pin assignments and mechanical requirements. Cable length, connector orientation, routing and other assembly parameters can be customized from prototype development through volume production.

Technical Specifications

Key Features

• HRS DF80 30-pin connector configuration
• Fine 40AWG micro coaxial cable
• Compact construction for high-density cable routing
• Suitable for high-speed signal interconnection
• Designed for space-constrained electronic equipment
• Custom cable length and pin assignment
• Custom connector orientation and cable routing
• Supports OEM, ODM and build-to-print manufacturing
• Suitable for prototype and mass-production requirements

Typical Applications

• Consumer electronics
• Display systems
• Camera and imaging equipment
• Embedded electronic devices
• Portable electronics
• Compact computing equipment
• High-speed internal signal connections
• Intelligent electronic equipment
• Robotics and vision systems

Customization Options

HOTTEN can customize the DF80 30-pin micro coaxial cable assembly according to the customer's electrical and mechanical requirements, including:

• HRS DF80 connector configuration
• 30-pin wiring and pin assignment
• 40AWG cable configuration
• Cable length
• Cable routing
• Connector orientation
• Bend direction
• Cable outer diameter
• Shielding configuration
• Termination requirements
• Labeling and identification
• Prototype and production packaging

For RFQ evaluation, customers can provide the HRS DF80 connector part number, pinout, cable length, wiring diagram, mechanical drawing and signal requirements.

Engineering & Procurement Considerations

For high-speed electronic systems, the cable assembly should be evaluated together with the equipment interface, signal requirements and mechanical installation conditions.

Important procurement parameters include:

For quotation, customers can provide an RFQ drawing, BOM, connector PN, pinout, cable length and mechanical requirements for engineering review.

Prototype to Mass Production

HOTTEN supports the complete product development process:

RFQ & Engineering Review → Prototype Sample → Electrical / Mechanical Validation → Design Confirmation → Pilot Production → Mass Production

Prototype samples can be used to verify connector mating, pin assignment, cable routing, dimensions and equipment integration.

After the design is approved, the confirmed drawing, BOM and inspection requirements can be used as the production reference for repeat and volume manufacturing.

Quality & Testing

Depending on customer requirements, inspection and testing can include:

• Pin-to-pin continuity testing
• Open and short circuit testing
• Pinout verification
• Electrical performance verification
• Connector appearance inspection
• Connector mating inspection
• Cable length and dimensional inspection
• Connector orientation inspection
• Workmanship inspection
• First Article Inspection (FAI)
• RoHS / REACH compliance documentation where required

For high-speed applications, additional electrical validation can be defined according to the customer's system specifications.

FAQ

Q1: Can HOTTEN manufacture an HRS DF80 30-pin cable assembly according to our drawing?
Yes. HOTTEN supports OEM, ODM and build-to-print manufacturing based on customer drawings and connector specifications.

Q2: What cable size is used for this product?
This product uses a 40AWG micro coaxial cable configuration.

Q3: Can the 30-pin pinout be customized?
Yes. Pin assignment and wiring can be customized according to the customer's electrical specification.

Q4: Can the cable length be customized?
Yes. The finished cable length can be manufactured according to the equipment's installation requirements.

Q5: What applications can use this DF80 cable assembly?
Typical applications include consumer electronics, display systems, compact computing equipment, imaging devices and other electronic systems requiring high-density high-speed signal interconnection.

Q6: Can the connector orientation and cable routing be customized?
Yes. Connector orientation, routing direction and bend configuration can be customized according to the mechanical design.

Q7: What information should be provided for an RFQ?
The recommended information includes the HRS DF80 connector part number, 30-pin pinout, cable length, wiring diagram, mechanical drawing, signal requirements and expected quantity.

Q8: Can HOTTEN provide prototype samples before mass production?
Yes. Prototype samples can be produced for electrical and mechanical validation before pilot and volume production.
