Ultra Fine 42AWG 60 Pin 0.4mm Pitch IP-EX 02680 Micro Coaxial Cable

Product Details

Product Overview

HOTTEN provides custom ultra-fine micro coaxial cable solutions for compact display and electronic systems where small cable size, fine conductor construction and high-density interconnection are important.

This cable features a 42AWG conductor configuration, 60-pin interface, 0.4mm pitch and IP-EX 02680 compatibility, making it suitable for LVDS/EDP display interconnection and compact electronic applications.

HOTTEN can support customized cable length, cable configuration, connector/interface requirements and assembly specifications according to the customer's application and drawings.

Key Specifications

Key Features

• 42AWG ultra-fine construction for compact electronic applications
• 60-pin high-density interconnection
• 0.4mm pitch for space-constrained designs
• IP-EX 02680 interface compatibility
• Suitable for LVDS and EDP display signal applications
• Designed for compact display and electronic systems
• Custom cable length and assembly configurations available
• Suitable for OEM and ODM cable development

Applications

Medical Display Systems
For compact medical display and electronic systems requiring high-density cable interconnection.

LVDS / EDP Display Systems
For display signal connections where fine-pitch and compact cable construction are required.

Compact Electronic Computers
For internal display and high-density electronic interconnections in space-constrained devices.

Custom Electronic Equipment
For OEM applications requiring a customized micro coaxial cable configuration.

Customization & Engineering Requirements

HOTTEN can customize the cable assembly according to your mechanical and electrical requirements.

Typical engineering information includes:

• Cable length
• Pin count and pin assignment
• Connector/interface configuration
• 0.4mm pitch requirements
• Conductor size
• Cable routing
• Termination requirements
• Assembly drawings
• Product samples or reference assemblies
• Prototype and production requirements

For RFQ evaluation, customers can provide drawings, BOMs, connector part numbers, pinouts and required cable lengths where available.

Engineering & Procurement Considerations

For compact LVDS/EDP cable assemblies, the connector interface, pitch, pin assignment and routing should be confirmed before production.

For OEM procurement, providing the original drawing or connector part number helps HOTTEN evaluate the cable construction and termination requirements more efficiently.

Prototype samples can also be evaluated before moving to regular production to confirm mechanical fit and assembly requirements.

FAQ

What is the pitch of this micro coaxial cable?
The listed product uses a 0.4mm pitch interface.

What conductor size is used?
The listed configuration uses 42AWG conductors.

How many pins does the cable have?
The listed configuration is a 60-pin cable.

Is this cable suitable for LVDS and EDP applications?
Yes. The product is listed as compatible with LVDS/EDP applications.

Is IP-EX 02680 supported?
Yes. The product is specified with IP-EX 02680 compatibility.

Can HOTTEN customize the cable?
Yes. Cable length, configuration and assembly requirements can be customized according to the customer's engineering requirements.

CTA

Need a customized 42AWG 60-pin micro coaxial cable for your LVDS/EDP application?

Send us your drawing, connector part number, pinout or sample requirements. HOTTEN can evaluate the cable construction and provide a customized solution for your application.
