Professional Custom Transmission Distance 2.5m 0.4mm OV6946 Lens Module Cable 5C(3X45AWG+2X46AWG)
|
Product name
|
5C(3X45AWG+2X46AWG)-PET
|
|
Conductor material
|
Silver plated copper alloy
|
|
outer diameter
|
OD=0.4mm
|
|
transmission distance
|
5m
|
|
Sheath Color
|
Blue
|
|
Sheath material
|
PET
|
|
packaging
|
250m/roll/piece
|
| Name | Material |
| Conductor | Silver plated copper |
| Tinned copper | |
| Silver plated copper alloy | |
| Tinned copper alloy | |
| Insulation | Teflon:PTFE/ePTFE/FEP/PFA |
| Shield | Tinned copper/Silver plated copper |
| CU/PET、 AL/PET | |
| Sheath | PFA/FEP/PTFE |
| Jacket | PVC/TPU/TPE/Silicone/PFA/FEP |
- Overview
- Recommended Products
Cable drawing: Overall construction, conductor layout and 0.4mm OD definition.
Electrical details: Conductor material, circuit assignment and required electrical characteristics.
Connection requirements: Connector part number, termination method and pin assignment.
Mechanical requirements: Finished length, dimensional tolerances, bend conditions and routing constraints.
Order requirements: Prototype quantity, expected production volume and inspection documentation.
Products Description
Product Overview
HOTTEN OV6946 Lens Module Cable is a customized 5-core cable designed for compact endoscope camera modules and miniature imaging equipment.
The specified configuration consists of 3 × 45AWG conductors and 2 × 46AWG conductors, with a target cable length of 2.5m and a nominal diameter of 0.4mm, subject to confirmation against the approved drawing.
HOTTEN supports OEM cable manufacturing based on customer drawings, reference samples, wiring diagrams and module interface requirements. The conductor arrangement, insulation, shielding, protective covering and termination can be defined according to the actual OV6946 module design.
Technical Specifications
| Item | Specification |
|---|---|
| Product Type | OV6946 Lens Module Cable |
| Camera Module | OV6946 |
| Core Configuration | 5C |
| Conductor Configuration | 3 × 45AWG + 2 × 46AWG |
| Cable Length | 2.5m |
| Nominal Outer Diameter | 0.4mm, confirm against the approved drawing |
| Cable Construction | According to the approved cable design |
| Conductor Material | To be confirmed |
| Insulation Material | To be confirmed |
| Shielding Construction | To be confirmed |
| Outer Sheath / Protective Covering | To be confirmed |
| Connector / Termination | According to module interface drawing |
| Pin Assignment | According to customer wiring diagram |
| Electrical Requirements | According to the approved module specification |
| Dimensional Tolerance | To be specified in the drawing |
| Application | OV6946 Camera Module / Endoscope Imaging Equipment |
| Manufacturing Type | Custom Camera Module Cable / OEM |
The 0.4mm value is treated as nominal cable OD. Confirm whether it applies to the complete cable or an individual cable element before production. The five-conductor arrangement should also be checked against the actual construction drawing.
Customization and Manufacturing Scope
HOTTEN supports build-to-print cable projects based on customer specifications.
| Customization Item | Required Information |
|---|---|
| Camera Module | OV6946 or the specified compatible module |
| Conductor Configuration | 3 × 45AWG + 2 × 46AWG |
| Finished Length | 2.5m, with tolerance defined by drawing |
| Cable OD | Nominal 0.4mm, with allowable tolerance specified |
| Conductor Material | Required metal, plating and conductor construction |
| Insulation | Required material and dimensional specification |
| Shielding | Required shielding structure, if applicable |
| Protective Covering | Sheath, tape or other specified construction |
| Connection Interface | Connector part number or direct termination requirements |
| Wiring | Pin assignment and circuit identification |
| Sample Requirements | Prototype quantity and approval criteria |
| Production Requirements | Estimated quantity and required inspection documentation |
Final material selection and termination details should be confirmed against the approved BOM and drawing. Optional construction choices should not be treated as included features until the configuration has been agreed.
Quality Inspection and Acceptance
The inspection plan should be defined before prototype approval and production.
| Inspection Item | Purpose |
|---|---|
| Cable Length | Verify the 2.5m finished length against drawing tolerance |
| Outer Diameter | Confirm nominal 0.4mm OD and applicable tolerance |
| Conductor Configuration | Verify the 3 × 45AWG + 2 × 46AWG arrangement |
| Continuity Test | Confirm the specified electrical paths |
| Pinout Verification | Check wiring against the approved diagram |
| Termination Inspection | Inspect the specified connector or termination |
| Electrical Testing | Perform applicable tests defined in the specification |
| Documentation | Maintain approved drawing revision and acceptance criteria |
Test methods, tolerance limits and sample quantities should be agreed upon for the actual product. Signal performance or transmission distance should not be claimed without a defined test specification and supporting results.
RFQ Requirements for OV6946 Lens Module Cable
For an accurate quotation, please provide:
HOTTEN can review the drawing, BOM or reference sample to confirm the required cable construction and manufacturing scope before quotation.
Request a Custom OV6946 Cable Quote
Submit your OV6946 module details, cable drawing, wiring diagram, required length and quantity for an engineering review and quotation.
