68C 50pF/m Ultrasound Probe Medical Handle Connection Cable for B-ultrasound Inspection

Product Overview

The HOTTEN 68-Core 50pF/m Medical Ultrasound Probe Handle Connection Cable is designed for B-ultrasound inspection equipment and compatible medical ultrasound probe systems that require multi-core signal connections.

Featuring a 68-core configuration and a specified capacitance of 50pF/m, this cable is intended for ultrasound probe and handle interconnection applications where electrical characteristics, cable dimensions and routing requirements must be considered together.

The cable construction can be configured according to project requirements, including conductor specifications, insulation, shielding, outer jacket, cable length and termination details. PVC, TPE and silicone jacket options are available within HOTTEN's ultrasound cable range, subject to the selected configuration.

HOTTEN supports customized cable development based on customer drawings, reference samples and technical specifications. Final capacitance, dimensional tolerances and other electrical and mechanical requirements should be confirmed against the approved cable specification.

Key Features

68-Core Cable Configuration

The 68-core construction accommodates multiple conductors within a single cable structure for ultrasound probe and handle connections. The conductor arrangement and electrical assignments should follow the equipment wiring diagram.

Specified Capacitance of 50pF/m

The 50pF/m capacitance specification provides an electrical design reference for the cable. The measurement method, test conditions, tolerance and whether the value applies to each signal line or a defined conductor pair should be confirmed before production.

Medical Ultrasound Probe Connection

The cable is intended for use in compatible B-ultrasound inspection equipment and medical ultrasound probe connections. The final construction should match the signal architecture and interface requirements of the target equipment.

Configurable Outer Jacket

PVC, TPE and silicone jacket options can be evaluated according to the cable design and application requirements. Jacket flexibility, color, outer diameter and environmental conditions should be defined for the specific project.

Custom Cable Development for OEMs

HOTTEN supports cable customization based on drawings, samples and project specifications. Core configuration, conductor size, cable length, shielding and connector termination can be reviewed according to the customer's requirements.

Technical Specifications

Final specifications depend on the approved drawing, sample and cable configuration. The 50pF/m value should be confirmed with its test conditions and tolerance.

Typical Applications

The 68-core ultrasound cable can be considered for:

• B-ultrasound inspection equipment

• Medical ultrasound probe connections

• Ultrasound probe handle interconnections

• Medical ultrasound transducer systems

• Customized diagnostic imaging equipment

The final application suitability depends on the required electrical characteristics, conductor arrangement, mechanical dimensions and equipment interface.

Engineering & Procurement Considerations

When specifying a 68-core ultrasound probe cable, engineers should evaluate capacitance, conductor configuration, mechanical routing and connection requirements together.

1. Capacitance and Electrical Performance

Confirm the required capacitance of 50pF/m, the permitted tolerance, the measurement method and the relevant conductor-to-conductor or conductor-to-shield test configuration. The stated value alone does not establish the performance of every signal path in the finished cable.

2. Core Configuration and Wiring

Provide a wiring diagram showing the conductor assignment and required connections. If different conductors carry different signal types, their electrical requirements should be identified in the cable specification.

3. Outer Diameter and Flexibility

Specify the required outer diameter, tolerance, minimum bend radius and routing conditions. These dimensions affect whether the cable fits the probe handle and the equipment installation space.

4. Jacket Material Selection

PVC, TPE and silicone may have different mechanical and environmental properties. Select the jacket according to the actual flexibility, cleaning, handling and operating requirements of the equipment. Any special material or compliance requirements must be confirmed for the exact configuration.

5. Shielding and Signal Requirements

Define the shielding construction and grounding requirements according to the equipment design. If the cable includes shielded signal paths, specify the required electrical acceptance criteria and shielding connections.

6. Sample Approval and Quality Control

Before production, confirm the approved drawing, cable sample, capacitance test conditions, continuity requirements, dimensional tolerances and other applicable electrical tests. The acceptance criteria should be documented before sample approval.

Custom Ultrasound Probe Cable Manufacturing

HOTTEN supports customized ultrasound cable development for medical equipment manufacturers based on drawings, existing cable samples and technical specifications.

For an engineering review or quotation, please provide:

• Required core count and conductor sizes

• Target capacitance and permitted tolerance

• Cable drawing or reference sample

• Required outer diameter and cable length

• Insulation, shielding and jacket requirements

• Connector part numbers and pin assignment

• Electrical testing and sample acceptance requirements

• Estimated order quantity and prototype requirements

HOTTEN can review the specified cable construction and manufacturing requirements to support customized ultrasound probe connection cable projects.

Request a Custom Ultrasound Cable Quote

Send your cable drawing, reference sample or electrical specification to discuss a customized 68-core, 50pF/m ultrasound probe cable for your B-ultrasound equipment application.
