I-PEX 20373 40-Pin 0.4mm-Pitch LVDS Micro Coaxial Cable
Product Overview
The HOTTEN I-PEX 20373 40-Pin LVDS Micro Coaxial Cable is intended for embedded display and drone system interconnections requiring a compact, multi-pin cable interface.
The specified configuration features a 40-pin I-PEX 20373-series connector interface with a 0.4mm pitch and micro coaxial cable construction. Connector compatibility, cable routing and electrical requirements should be confirmed against the target equipment design before the cable configuration is finalized.
HOTTEN supports cable projects based on customer drawings, samples and connector specifications. The final cable structure and assembly scope should be agreed according to the approved technical documentation.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | LVDS Micro Coaxial Cable |
| Connector Series | I-PEX 20373 series |
| Pin Count | 40-pin |
| Connector Pitch | 0.4 mm |
| Cable Construction | Micro coaxial |
| Signal Interface | LVDS, subject to system verification |
| Application | Embedded Display and Drone Systems |
| Cable Length | Project-specific |
| Conductor Gauge | To be confirmed |
| Characteristic Impedance | To be confirmed |
| Opposite-End Connector | To be confirmed |
| Pin Assignment | Per approved drawing |
Applications
This cable is intended for embedded display and drone system interconnection projects where connector dimensions, cable routing and signal requirements must match the equipment design.
For embedded display applications, the connector interface and signal mapping should be checked against the display module and mainboard specifications.
For drone-related applications, cable length, connector orientation and installation space should be reviewed against the camera, display or electronic module design. The actual application should be confirmed before the cable is selected for a specific system.
Connector Configuration and Cable Integration
The 40-pin interface and 0.4mm pitch are important identification parameters for this product. However, the connector series alone does not define the complete cable assembly.
Before production, the full connector part number, mating connector, opposite-end termination, pin assignment and required cable length should be confirmed. Any specified impedance, signal-integrity or shielding requirements should also be documented in the approved drawing.
If the project requires a completed cable assembly, the connector configuration, termination method and inspection criteria should be agreed before production.
RFQ Information
For quotation and technical review, please provide the cable drawing or sample, complete connector part numbers, required cable length, pin assignment and applicable electrical requirements.
These details help establish the correct cable configuration for the target embedded display or drone system.
