High-Resolution IVUS Imaging Wire Cable

Product Overview

High Resolution IVUS Imaging Wire Cable for Intravascular Ultrasound Systems

HOTTEN provides customized IVUS imaging wire cable solutions designed for intravascular ultrasound systems requiring precise signal transmission and compact cable structures.

Our high-resolution IVUS cables are engineered with optimized conductor designs, advanced insulation materials and shielding structures to support demanding cardiovascular imaging applications.

HOTTEN supports medical device manufacturers with customized cable development, prototype production and mass manufacturing.

Key Features

Precision IVUS Imaging Cable Solution

🔹 High Resolution Signal Transmission

Designed to support accurate signal transmission for advanced IVUS imaging systems.

🔹 Ultra Thin Cable Structure

Suitable for catheter-based medical applications with strict size requirements.

🔹 Low Signal Interference

Shielding structures help maintain stable imaging performance.

🔹 Flexible Medical Cable Design

Supports bending requirements in compact medical devices.

🔹 OEM Customization Support

Cable diameter, conductor structure and materials can be customized.

Cable Structure

Customized IVUS Cable Configuration

根据 HOTTEN 当前资料：

Conductor

Options:

• Silver plated copper
• Tinned copper
• Silver plated copper alloy
• Tinned copper alloy

Insulation

Options:

• PTFE
• ePTFE
• FEP
• PFA

Shielding

Options:

• Tinned copper shielding
• Silver plated copper shielding
• CU/PET
• AL/PET

Jacket

Options:

• PVC
• TPU
• TPE
• Silicone
• PFA
• FEP

Applications

IVUS Medical Imaging Applications

Suitable for:

🫀 Intravascular Ultrasound Systems

🩺 Coronary Imaging Catheter Systems

🔬 Cardiovascular Diagnostic Devices

🏥 Interventional Medical Equipment

🏭 Medical Device OEM Applications

Customization Options

OEM IVUS Cable Manufacturing

HOTTEN supports:

✔ Ultra-thin diameter customization

✔ Core configuration

✔ AWG selection

✔ Impedance optimization

✔ Shielding design

✔ Insulation material selection

✔ Connector assembly

✔ Prototype development

✔ Mass production

Quality Assurance

Precision Medical Cable Testing

Testing includes:

✔ Electrical continuity testing

✔ Insulation resistance testing

✔ Withstand voltage testing

✔ Dimensional inspection

✔ Mechanical bending testing

✔ Signal performance testing

Engineering & Procurement Considerations

What Engineers Should Consider When Selecting a High-Resolution IVUS Imaging Wire

A high-resolution IVUS imaging wire is used within intravascular ultrasound systems where stable signal transmission and precise imaging performance are important. Cable selection should consider signal integrity, shielding, conductor configuration, compact construction, flexibility, impedance characteristics and connector compatibility as part of the complete imaging system.

For high-resolution intravascular imaging applications, the cable should be designed according to the electrical and mechanical requirements of the imaging system and catheter assembly.

Key Engineering Requirements

Key Procurement Parameters

When sourcing a high-resolution IVUS imaging wire, procurement teams should define:

Signal Integrity Considerations for High-Resolution IVUS

For high-resolution intravascular imaging, the cable should be evaluated as part of the entire signal path.

Important parameters may include:

• Conductor configuration

• Cable geometry

• Dielectric characteristics

• Shielding structure

• Impedance

• Cable length

• Connector termination

• Internal routing

• Bending conditions

Changes to any of these parameters may affect the overall electrical behavior of the cable, so they should be considered together during engineering development.

Shielding and EMI Control

The shielding structure should be selected according to the imaging system's signal sensitivity and electromagnetic environment.

Potential shielding configurations may include:

• Tinned copper shielding

• Silver plated copper shielding

• CU/PET shielding

• AL/PET shielding

The final shielding construction should be determined according to the customer's electrical specification and system architecture.

Compact and Flexible Construction

Intravascular imaging systems place significant constraints on cable dimensions and routing.

Engineers should consider the relationship between:

Cable Diameter + Electrical Performance + Flexibility + Shielding + Connector Size

A high-resolution IVUS cable should achieve the required electrical characteristics without creating unnecessary mechanical restrictions within the catheter assembly.

OEM Customization

HOTTEN supports customized high-resolution IVUS imaging wire development based on customer drawings and technical specifications.

Customization can include:

• Conductor configuration

• AWG selection

• Conductor material

• Insulation material

• Shielding structure

• Impedance optimization

• Cable diameter

• Cable length

• Jacket material

• Connector assembly

• Termination configuration

• Prototype samples

• Mass production

The cable structure can be adapted to the customer's imaging architecture rather than limited to a fixed standard configuration.

Supplier Evaluation Checklist

When evaluating a supplier for high-resolution IVUS imaging wire, procurement teams should consider:

① High-Precision Cable Manufacturing
Can the supplier manufacture compact and dimensionally controlled medical imaging cables?

② Signal Integrity Capability
Can the supplier work with conductor geometry, dielectric structure, shielding and impedance requirements?

③ Shielding Capability
Can the supplier provide multiple shielding configurations according to the system requirements?

④ Miniature Flexible Construction
Can the supplier balance electrical performance with the mechanical constraints of the catheter assembly?

⑤ Engineering Customization
Can the supplier work from drawings, BOMs, electrical specifications and connector requirements?

⑥ Prototype-to-Mass-Production Capability
Can the same supplier support engineering samples and recurring production?

Recommended RFQ Information

For an accurate engineering review and quotation, customers should provide:

• IVUS system or catheter application

• Required signal or imaging specifications

• Cable drawing

• Core configuration

• Conductor and AWG requirements

• Target impedance, if applicable

• Maximum cable diameter

• Shielding requirements

• Insulation and jacket requirements

• Cable length

• Connector model and part number

• Pinout / termination information

• Flexibility or bending requirements

• Prototype quantity

• Expected production volume

• Required electrical and mechanical testing

HOTTEN High-Resolution IVUS Cable Engineering Support

HOTTEN provides customized medical imaging cable solutions for IVUS and intravascular imaging applications. Cable construction can be configured around the customer's requirements for conductor, insulation, shielding, impedance, dimensions, flexibility and termination, with support for prototype development and mass production.
