Medical Ultrasound Cable Assembly

High-Density Cable Solutions for Ultrasound Probe and Medical Imaging Equipment

🏥 Modern medical imaging systems require cable assemblies with excellent signal integrity, flexibility, durability, and high-density wiring capability.

Hotten provides customized medical ultrasound cable assemblies designed for ultrasound probes, diagnostic imaging systems, and precision medical equipment.

By integrating micro coaxial cable technology, multi-core conductor structures, shielding design, and precision assembly processes, Hotten delivers reliable cable solutions for medical OEM manufacturers requiring stable signal transmission and long-term performance.

🩺 Applications of Medical Ultrasound Cable Assembly

Hotten ultrasound cable assemblies are widely used in:

• Ultrasound Probe Systems
• Diagnostic Imaging Equipment
• Medical Monitoring Devices
• Portable Ultrasound Systems
• Surgical Imaging Equipment
• Hospital Diagnostic Equipment
• Medical Testing Instruments

For ultrasound equipment manufacturers, cable performance directly affects signal quality, image accuracy, and device reliability.

🔬 High-Density Medical Cable Technology

Ultrasound equipment requires cables capable of transmitting multiple sensitive signals while maintaining flexibility during repeated movement.

Hotten medical ultrasound cable assemblies feature:

• High-density multi-core cable construction
• Micro coaxial signal transmission technology
• Low capacitance design
• Individual signal shielding
• EMI interference protection
• Flexible cable routing
• Customized connector integration

The high-density structure allows more signal channels to be integrated into compact medical devices while maintaining reliable electrical performance.

⚙️ Customized Ultrasound Cable Assembly

Hotten supports OEM customization according to customer drawings, samples, connector requirements, and medical equipment applications.

Cable Structure

• Multi-core ultrasound cable
• Micro coaxial cable structure
• High-density signal cable
• Shielded medical cable
• Custom cable diameter and configuration

Electrical Performance

• High-frequency signal transmission
• Low capacitance characteristics
• Signal interference reduction
• Stable impedance control
• Reliable electrical performance

Mechanical Design

• Flexible bending capability
• Lightweight cable structure
• Wear-resistant outer jacket
• Custom cable length
• Long service life under repeated movement

Connector & Assembly

• Customized medical connectors
• PCB termination
• Custom pin assignment
• Precision soldering
• Complete OEM cable assembly

🏭 Medical Ultrasound Cable Manufacturing Process

Hotten follows a controlled manufacturing process for medical cable assemblies:

Material Selection

↓

Precision Wire Processing

↓

Micro Coaxial / Multi-Core Assembly

↓

Connector Termination

↓

Electrical Performance Testing

↓

Finished Ultrasound Cable Assembly

From prototype development to mass production, Hotten supports medical equipment manufacturers with customized cable solutions.

📋 Technical Specifications

Item | Specification

Cable Type | Medical Ultrasound Cable Assembly

Application | Ultrasound Probe / Diagnostic Imaging Equipment

Cable Structure | Multi-Core Cable / Micro Coaxial Cable

Conductor | Silver Plated Copper / Copper Alloy

AWG Size | Customized (28AWG–46AWG)

Number of Conductors | Customized Multi-Conductor Design

Capacitance | 54pF/m Customized Low Capacitance Design

Shielding | Individual Shield / Overall Shield

Insulation | FEP / PFA / TPU

Jacket Material | Silicone / TPU / PVC Customized

Operating Temperature | -40℃ to +80℃ Customized

Connector | Medical Probe Connector / PCB Connector Customized

Customization | Length, connector, pin assignment, cable structure

⭐ Why Choose Hotten

Precision Medical Cable Manufacturing

Hotten specializes in customized electronic wires and cable assemblies for medical equipment and high-performance electronic applications.

High-Density Signal Transmission

Advanced micro coaxial and shielding structures help maintain signal quality in complex medical imaging systems.

OEM Customization Capability

Cable structure, conductor size, connector type, length, and assembly requirements can be customized according to customer specifications.

Prototype to Mass Production

Hotten supports the complete development process from engineering samples to stable volume manufacturing.

🔗 Related Cable Solutions

Medical Cable Assembly

Ultrasound Probe Cable

Endoscope Cable

Micro Coaxial Cable Assembly

High Density Cable Assembly

Custom Cable Assembly

🤝 Need a Customized Medical Ultrasound Cable Assembly?

If your medical equipment requires ultrasound probe cables, high-density medical cable assemblies, or customized OEM cable solutions, send Hotten your drawings, samples, connector specifications, or technical requirements.

Hotten provides professional cable customization services from prototype development to mass production.

Request a Customized Medical Cable Solution →
